Core Value
The 220V Stainless Steel Hot Runner Coil Heater with Braided Thermocouple Wire is designed for high-density, precise thermal management in demanding plastic injection molding nozzles, hot runner manifolds, and packaging equipment. Featuring a compacted MgO insulation core wrapped in a premium stainless steel sheath, this heater incorporates an integrated Type J or Type K thermocouple shielded by heavy-duty Metal Braided Armor Wire.
This rugged wire construction protects both power leads and sensor wiring against mechanical crushing, sharp mold edges, and continuous machine vibration. Capable of operating continuously at temperatures up to 650°C (1202°F), it delivers 360° uniform thermal distribution, rapid warm-up, and real-time closed-loop PID feedback to eliminate gate freeze-off and polymer degradation. BACKED BY 30+ YEARS MANUFACTURING EXPERIENCE and UNDERGOES MULTIPLE RIGOROUS QUALITY CHECKS for continuous, maintenance-free operation.
- ✓ Heavy-Duty Braided Wire Shielding: Stainless steel metal braid protects power and thermocouple leads from abrasion, crushing, and bending stress.
- ✓ Integrated Temperature Sensing: Built-in Type J/K thermocouple wire ensures instantaneous thermal feedback directly at the nozzle wall.
- ✓ 220V High Watt Density Performance: Precision compacted core enables fast thermal response and uniform heat distribution.
- ✓ Extreme Temperature Resilience: Operates continuously up to 650°C (1202°F) for processing high-temperature engineering resins.
- ✓ Sealed Transition Crimp: Moisture and contamination-resistant junction protects internal wiring from melted plastic leakage.
✓ Precision Coiled Fit: CNC lathe coiling ensures zero air gaps and maximum contact surface with injection nozzles.
- ✓ Reliable Quality: 30+ YEARS MANUFACTURING EXPERIENCE guarantees long operational lifespan.
- ✓ Quality Assured: UNDERGOES MULTIPLE RIGOROUS QUALITY CHECKS including high-voltage insulation and grounding continuity tests.
- ✓ Global Compliance: CE, LVD, RoHS, and ISO 9001 certified.
Technical Specifications & Performance Data
| Parameter | Standard Value | Customizable Range | Notes |
| Voltage Rating | 220V AC (Single Phase) | 110V / 230V / 240V / 380V | Compatible with standard mold temperature controllers |
| Sheath Material | Stainless Steel 304 / 316L | Incoloy 800 / High-Temp Alloys | High oxidation resistance under thermal cycling |
| Thermocouple Wire | Built-in Type J (Fe-CuNi) or Type K | Grounded / Ungrounded Junction | Shielded inside stainless steel metal braid sleeve |
| Lead Protection | Stainless Steel Braided Armor Wire | Kevlar Sleeving / Silicone / PTFE | Superior flexibility and high mechanical abrasion resistance |
| Max Operating Temp | 650°C (1202°F) | Up to 700°C short-term peak | Resists sheath warping and element burnout |
| Watt Density | 5.0 – 8.0 W/cm² | Up to 12.0 W/cm² | Engineered for rapid heat transfer and recovery |
| Cross Section | 2.2 × 4.2 mm / 3.0 × 3.0 mm | Flat, Square, or Round profiles | Custom cross-section for maximum thermal contact |
| Coil Inner Diameter | Ø10 mm – Ø50 mm | Built to nozzle drawings | Precision lathe coiled (±0.02 mm) |
| Lead Wire Length | 1000 mm Standard | Custom Lengths (e.g., 1500 mm / 2000 mm) | High-temperature nickel conductors |
| Warranty | 1 Year Standard | Extended coverage available | Guaranteed against manufacturing defects |
Industrial Applications & Solutions
- Hot Runner Injection Nozzles: Concentrated thermal profile management for single and multi-cavity injection molds, eliminating nozzle drooling and stringing.
- PET Preform Mold Systems: Maintains precise, balanced temperature control across high-cavitation PET bottle preform nozzle tips.
- Engineering Plastic Processing: Efficiently processes high-temperature polymers including PEEK, PEI, PPS, and glass-filled Nylon.
- Packaging Sealing Jaws & Form-Fill-Seal Equipment: Direct heating in packaging machinery requiring continuous lead movement and tough wire protection.
- Medical Device Component Injection: Delivers clean, stable heat distribution required for medical-grade plastic injection molding.
HT-Heater vs Standard Market Heaters
| Feature | HT-Heater (Factory) | Standard Market | Your Advantage |
| Wire Armor Quality | Heavy-Duty SS Braided Armor Sleeve | Loose / Thin Fiber Sleeve | Extreme resistance to mechanical pinching and abrasion |
| Thermocouple Fit | Fully Integrated Braided Sensor Wire | External Loose Sensor Wire | Direct contact temperature sensing, zero thermal lag |
| Thermal Limit | Continuous operation up to 650°C | Burnout / warps above 400°C | Handles extreme watt densities safely |
| Transition Head | Sealed Heavy-Duty Strain Relief Crimp | Open Loose Crimp Connection | Prevents wire breakage and plastic leak contamination |
| Manufacturing Exp. | 30+ YEARS EXPERIENCE | Unverified Workshops | Proven nozzle coiling and thermal engineering |
| Quality Assurance | MULTIPLE RIGOROUS QUALITY CHECKS | Basic Resistance Test Only | ZERO DEFECT DELIVERY |
Installation & Integration Guidelines
- Nozzle Surface Cleaning: Thoroughly clean the nozzle mating surface to remove carbonized plastic, oil, and debris prior to installing the coil heater.
- Smooth Slide Fitting: Gently slide or expand the coiled heater onto the nozzle body. Never strike the element with a metal hammer to prevent damaging internal MgO insulation.
- Braided Wire Routing: Route the braided thermocouple and power wires through mold wire channels. Secure wires with clamping plates to prevent strain during mold cycling.
- Thermocouple Polarity: Connect thermocouple leads using correct color polarity (For Type J: White = Positive, Red = Negative) to your PID controller.
- Initial Bake-Out Cycle: Run a low-voltage pre-heating cycle at 100°C – 120°C for 10 minutes to eliminate ambient moisture absorbed by insulation before ramping up to full 220V power.
Customer Success Stories
Case 1:
Automotive Injection Molder (Germany)
-
Application: Multi-cavity hot runner mold producing glass-filled polyamide (PA66-GF30) interior components.
-
Challenge: Standard lead wires were routinely severed or pinched during rapid mold plate clamping cycles.
-
Solution: 220V Stainless Steel Hot Runner Coil Heaters with Stainless Steel Braided Thermocouple Wire.
-
Results: WIRE-RELATED DOWNTIME REDUCED TO 0%. “The metal braided wire protection is exceptionally durable. HT-Heater UNDERGOES MULTIPLE RIGOROUS QUALITY CHECKS, and their batch quality is excellent.”
Case 2:
PET Bottle Mold Manufacturer (Brazil)
-
Application: 48-cavity hot runner PET bottle preform nozzle system.
-
Challenge: Inaccurate thermal readings from external sensors caused temperature fluctuation and gate freeze-off.
-
Solution: Custom 220V Stainless Steel Coil Heaters with integrated braided Type J thermocouples.
-
Results: REJECT RATE REDUCED BY 15%. “30+ YEARS MANUFACTURING EXPERIENCE is clear in their thermal design. The integrated braided thermocouple gives perfectly stable PID response across all cavities.”
Pricing & Procurement Options
-
-
-
-
Standard Production: MOQ 10 pieces. BACKED BY 30+ YEARS MANUFACTURING EXPERIENCE ensuring exact dimension repeatability across production runs. Tiered OEM discounts available for 50+ units.
-
Lead Times: Standard Stock Sizes: 3-5 days. Custom Coiling & Wire Configurations: 7-10 days. Express sample dispatch available for urgent mold repairs.
-
Global Logistics: Express delivery via DHL, FedEx, UPS, or air freight. Packed securely in anti-static bags and protective export cartons.
-
Sample Orders: Custom samples manufactured upon CAD drawing approval. Every unit UNDERGOES MULTIPLE RIGOROUS QUALITY CHECKS prior to dispatch.
-
-
-
Global Certifications & Compliance
- CE Marking
Fully compliant with European safety and environmental standards. - LVD Compliance
Low Voltage Directive tested for continuous thermal load safety. - RoHS Compliant
Constructed using environmentally safe, lead-controlled brass alloys. - ISO 9001
Certified quality control covering CNC machining, coil pressing, and electrical testing.
Quality Documentation: Certificate of Conformity (COC) and insulation resistance test reports included.
Comprehensive After-Sales Support
-
- Warranty: 1-Year Comprehensive Warranty covering internal heating element and built-in sensor.
-
Technical Support: Application engineers available for wattage distribution calculation, thermocouple calibration, and nozzle fitting assistance.
-
Global Response Network: BACKED BY 30+ YEARS MANUFACTURING EXPERIENCE with technical inquiry feedback within 2 hours.
Ready to Optimize Your Injection Molding?
Next Steps:
- 📧 Request Custom Quote – Send your nozzle dimensions, wattage, voltage, and HT-CLW-450 drawing requirements.
- 🔧 Free Design Consultation – Work with our thermal engineers to optimize heat distribution and lead insulation.
- 📦 Order Test Samples – Evaluate thermal performance on your injection molding machine.
- 📞 Contact Hot Runner Experts – Response within 2 hours
-
